WARNING B4 PROCEED
I JUZ SHARING THE INFO . IF ANY DAMAGE HAPPEN TO YOUR LAPTOP OR YOUR DEVICE , I'LL NOT BE RESPONSIBLE FOR IT . THIS MAY AVOID YOUR WARRANTY ALSO .
WARNING : THIS ALSO MAY INCREASE YOUR CPU AND GPU TEMPERATURE IF DON'T HAVE PROPER COOLING . AND OVERCLOCKING MAY SHORTEN YOUR DEVICE LIFESPAN IF YOU NOT HAVE A PROPER COOLING AND GOOD AIRFLOW.
Credit Goes To This Guy For My Trial And Error :
http://slappablog.com/2011/12/08/laptop-llano-sabine-overclocking-guide-a4-3300m-a6-3400m-a8-3500m/
Or more specifically I’ll be explaining overclocking the:
HD 7670M
AMD A6-3420M
This guide comes with absoulutely no warranty. This may damage your hardware, it will void your warranty, follow this guide at your own risk.
Overclocking the A6-3420M
Because the APU is much easier to overclock than the GPU, that’s what I’m going to explain first. The first thing you should do is update AMD Vision Engine (Shortened to AVE), you can do so with this.
The next thing you should do is open AVE (Right-click your desktop, click “Graphics Properties”). In AVE, click “Preferences” in the top-right, and select “Advanced View”. In the left pane, click “Performance » AMD OverDrive”.
Now that you’re in the AMD OverDrive settings, click “Overrride existing CPU settings”, then click “Auto-Tune”. At any point if it asks you if you’re sure, or it explains that doing so will void your warranty, agree if you wish. After Auto-Tune is finished, enable AMD OverDrive (On the OverDrive pane, there will be a slider at the bottom, to the top-left of the slider should be a big button, click it so it’s green). You should have options all the way up to 1.9GhZ (At least, anyways), this does not effect “turbo” (You can download the full version of AMD OverDrive to do that if you wish, I will not be covering that), I set mine to 1.7GhZ because I found 1.9GhZ (and 1.8GhZ) ran a little too hot.
Congratulations! You’ve just overclocked your 3420M!
[b]THE BETTER WAY TO OVERCLOCK YOUR APU IS USING K10STATS(much better than fusion tweaker) ~Fusion Tweaker is same as k10stats but simplier interface n easily use ~[/b]
[b]Overclocking the HD 7670M[/b]
(If you haven’t updated AVE, do that now) First thing to do is install MSI Afterburner (If you prefer Sapphire TRIXX, that works too, I won’t be covering it though), you can get a copy of it here. Next, make sure Afterburner and AVE are closed before proceeding (You may wish to reboot your computer).
First thing to do is open regedit (Start » “regedit”). Hit “Edit » Find”, and type in “enableulps”, search. Wait for it to complete, after it finds it, double-click “enableulps” and change it’s value from 1 to 0. Hit “F6” to find the next entry of “enableulps”, it probably won’t find one but do it just to be safe.
Now open the folder Afterburner installed to (Probably “C:\Program Files (x86)\MSI Afterburner”) and open “MSIAfterburner.cfg”, in Notepad. Find the line that says “UnofficialOverclockingEULA =”, and add “ I confirm that I am aware of unofficial overclocking limitations and fully understand that MSI will not provide me any support on it” to the end of it. Next, the line below it “UnofficialOverclockingMode”, change to “0” to a “1”. Now reboot your computer (This is required to disable ulps, which is required to use AfterBurner, if you don’t do this, you may need to do the regedit step again).
Now run Afterburner (Start » All Programs » MSI Afterburner » MSI Afterburner). Set “Core Clock” to “700”, and “Memory Clock” to “1050”, then hit “Apply”. Next click “Save”, then click the first profile. Now your GPU should run (While gaming) at about 66-68 Celcius, capping at 70. It may run hotter depending on what game you’re playing, I tested this with Diablo III (Which ran my GPU at a max of 88% so it can likely get warmer), it should cool down to as low as 43 within 20mins of little-no use, 50 in 5mins of little-no use, and 53-54 in 1-2mins of little-no use.
If you have an issue regarding “ulps”, reboot your computer (Make sure MSI Afterburner isn’t set to start on startup first), and go back to the regedit step. If you can’t raise your clocks beyond the stock, close Afterburner (or reboot your computer, and make sure it doesn’t start on startup) and go back to the Afterburner configuration step.
Congratulations! You’ve just overclocked your 7670M!
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
My Review :
I did this method and successfully overclock my ASUS A43TK VX024 proc to 2.9 GHz .
This is my lappy spec :
Windows 8 Pro with Media Center
AMD A6 3420M with integrated graphic( Radeon HD6520g) Oced to 2.9GHz
6GB DDR3 RAM
500GB HDD SATA
ATI Radeon HD7670M ( 835MHz / 1180MHz )
My GPU Overclock(FINAL AND STABLE):
Core Clock : 835MHz Mem Clock: 1180MHz ( 865 MHz / 1210MHz stable for me for some program )
[b]FOR BETTER AND STABLE FOR SOME USER : CORE CLOCK: 700~780MHz MEMORY CLOCK: 1000~1170MHz
[b]BENCHMARKING RESULT (3DMARK VANTAGE OR OTHERS LIKE UNIENGINE OR OTHERS ARE NOT TESTED .)
Benchmarking is tested on 1366x768 max resolution . Antialiasing and Vsync is turned on if the fps was stable . Old games will run fine on maxed settings .Some games run with or without patch . Test were running using my final and stable clock ( may vary different than your gpu oc clock since i run it higher than most user did )
35FPS+ on Battlefield 3 on ultra( without MSAA ) - some maps will run at 40 and above -
25FPS+ on Crysis 2 (Extreme settings , DX11 , Vsync on , HD Texture Pack )
60FPS+ on PCSX2 ( depend on games , final fantasy x-2 and initial D running solid 60FPS )
30FPS+ on Dolphin Emulator playing Fatal Frame IV
50FPS+ on Resident Evil 5 gameplay all settings are high
45FPS+ on Call Of Duty Modern Warfare 3 all Very High Setting with native image setting on and 4x Antialiasing plus Vsync
35FPS+ on Battlefield Bad Company 2 with all High Setting running in Directx 11 with AA
50FPS+ on Binary Domain with all highest setting
25FPS+ on Ghost Recon Future Soldier Max setting
40FPS+ on Max Payne 3 ( Running on DirectX 11 , Everything MAX , AA 2X ,vsync on )
45FPS+ on Race Driver Grid max setting
30FPS+ on Medal Of Honor Warfighter ULTRA settings ( without antialiasing )
35FPS+ on DIRT 3 ultra settings with AA and Vsync
35FPS+ on Homefront with all highest settings
50FPS+ on Gear Of War with latest patch and running on Directx 10 with antialiasing
45FPS+ on Metro 2033 running on Directx10 with highest settings ( Directx 11 will gives a glitch : black bars )
55FPS+ on Counter-Strike Global Offensive with max setting
40FPS+ on Doom BFG edition highest settings
35FPS+ on Dawn of War II Series ( Max Setting with AA)
55FPS+ on Dishonored ( Max Setting with AA)
55FPS+ on Call of Duty 4 Modern Warfare ( Max Setting with AA)
35FPS+ on Starcraft II ( ultra , vsync on , reduce mouse lag off )
45FPS+ on Singularity ( with some registry tweaks , vsync on , no AA )
45FPS+ on X-Men Origin : Wolverines ( Tweaked settings )
40FPS+ on Deus Ex Human Revolution ( All max even on catalyst set at 8x antialiasing ~Directx11 )
30FPS+ on Lost Planet 2 ( All max running DirectX 11 settings without AA n Vsync)
35FPS+ on Alan Wake ( Max Settings )
35FPS+ on Warhammer 40k Space Marine ( Max settings )
35FPS+ on All Assasins Creed Series ( first ~ revealation )
35FPS+ on Silent Hill Homecoming( Max settings )
45FPS+ on The Darkness II ( all max )
35FPS+ on FEAR 3 ( all max )
30FPS+ on Need for Speed Most Wanted 2012 ( all max )
45FPS+ on RAGE ( all max and patched up)
35FPS+ on James Bond BloodStone ( max except AA set to 4x )
30FPS+ on Call of Duty Black Ops II ( maxed out settings with 8x AA)
40FPS+ on Dead Space 2 ( All maxed out vsync off)
50FPS+ on Street Fighter IV Benchmark ( All Maxed Out )
25FPS+ on Assasins Creed III ( all maxed out except antialiasing quality set to high, sometimes the fps go 30fps to 45fps )
45FPS+ on Sniper Ghost Warrior ( Maxed out )
30FPS+ on DiRT Showdown ( Maxed Out )
30FPS+ on Alan Wake American Nightmare ( Max Setting with AA)
30FPS+ on New Slender Game ( Maxed out ) ( [url=http://www.haunt-slendergame.com/]http://www.haunt-slendergame.com/[/url] ) < nice graphic and gameplay kinda scary too ..
45FPS+ on The Walking Dead ( Max Out )
35FPS+ on Operation Flashpoint Red River ( Maxed Out )
25FPS+ on Crysis ( 8XMSAA ,VSYNC , VERY HIGH ) ( much better looking wif blackfire mods : [url=http://postimage.org/image/duoffv0un/]http://postimage.org/image/duoffv0un/[/url] )
25FPS+ on L.A. Noire ( Maxed out , except shadow and lightning are set to balanced running on DirectX 9 )
30FPS+ on Far Cry 3 ( Ultra settings without AA , vsync OFF , gpu render set to 1 or 2 and set the shadow to medium plus postfx to low ~ )
55FPS+ on Portal 2 ( Max settings with AA X8 and Vsync)
25FPS+ on Hitman Absolution ( all maxed out except shadows set to medium , 2x antialiasing )
50FPS+ on Tomb Raider Underworld ( Maxed Out )
35FPS+ on Ridge Race Unbounded ( Max Setting with AA)
50FPS+ on Dota 2 ( Max Setting with AA)
40FPS+ on DMC 2013 Max Setting ~
35/45FPS+ on Dead Space 3 ( Max setting ,Vsync off )
40FPS+ on Modern Warfare 2 (Max sett. in SP )
20FPS+ on World Of Tank ( Max Sett. )
25FPS+ on PlanetSide 2 ( Max Sett. )
40FPS+ on Alien Colonial Marines ( Max Sett. with vsync but the game kinda stutter without reason :/ even though on low setting ~)
23FPS+ on Crysis 3 ( High Setting with 2x AA with vsync / Go for medium setting or lower if u wanna boost ur fps)
24FPS+ on Tomb Raider 2013 ( set on high / Custom setting with FXAA n Triple Buffer Vsync plus TressFX ~ see picture link below )
25FPS+ on Sniper Elite Nazi Zombie Army ( Ultra sett. without AA )
30FPS+ on Call Of Duty 2 ( Max Sett. )
45FPS+ on Sniper Ghost Warrior 2 ( Very High setting with AA n vsync )
40FPS+ on Sleeping Dogs ( Max Setting )
45FPS+ on Resident Evil 6 ( Max Setting )
25FPS+ on Starcraft II Heart Of Swarm ( Extreme with Antialiasing )
35FPS+ on God Mode ( Everything on Max )
25FPS+ on Bioshock Infinite ( Ultra Setting )
45FPS+ on Dead Island Riptide ( everything max )
30FPS+ on Farcry 3 Blood Dragon ( Same setting as FC3 )
60FPS+ on Scribblenauts Unlimited ( 8X Antialiasing ~ haha ~ )
50FPS+ on Grand Theft Auto IV ( Max Setting ) < games kinda unoptimized :/ low fps sometimes
25FPS+ on The Elder Scrolls V Skyrim ( Max Setting with 4X AA)
30FPS+ on The Witcher 2 - Assassins of Kings Enhanced Edition ( Max except ubersampling and using this tweak : documents > witcher 2 > config > user - change TextureMemoryBudget to 1536 or 900 )
20FPS+ on Metro Last Light ( Max except SSAA n Tesselation , motion blur set to low )
25FPS+ on Ace Combat Assault Horizon Enhanced Edition ( Max Setting )
60FPS+ on Left 4 Dead 2 ( Max Setting 8x AA)
50FPS+ on Resident Evil Revelation ( Max Setting as possible )
40FPS+ on Call Of Juarez Gunslinger ( Max as posibble )
25FPS+ on GRID 2 ( Ultra with 4X AA )
50FPS+ on Remember Me ( All Maxed Out except supersampling )
30FPS+ on Of Orc And Men ( Default setting )
30FPS+ on Deadpool ( Max Setting )
DONT FORGET TO CHECK OUT SOME OF MY INGAME AND SETTINGS SCREENSHOT ( INCLUDE PERFORMANCE TEST AND OTHERS )
https://plus.google.com/photos/112873566127639725599/albums/5853426560543694433?authkey=CPLA-6-n9qLD8AE]https://plus.google.com/photos/112873566127...CPLA-6-n9qLD8AE
-Software rendering will be much faster when running higher clocks.-
IF YOUR TEMPS. GET HIGH OR WANT TO PUSH YOUR OVERCLOCK HIGHER , OPEN THE RAM AND HDD COVER PLATE AND CHANGE THE THERMAL PASTE INSIDE THE LAPTOP . THAT SHOULD DO .
Most of the new game can run pretty decent and playable at max settings , depend on their game engine and settings . The benchmarking result was benchmarked by myself by running it and test it on several games .
This also compatible with A4 ,A6, A8 , and A10 mobile processor.
You can also use FusionTweaker to overclock your processor successfully.
Here are some tips for the airflow :
- Please do this overclocking on a flat and hard surface ( e.g. marble floor not wooden floor )
- give a space for the laptop
- do it in air conditioned room is recommended
- put a big fan beside ur lappy
- buy a cooler of course
warning on the overclocking the CPU and GPU :
-DON'T PUSH THE VOLTAGE TOO MUCH
-STAY ALERT ON THE TEMP
-DON'T OVERCLOCK TOO MUCH
-BE FRIENDLY WITH YOUR HARDWARE
-LOWER THE CLOCK IF THE TEMP WAY TOO MUCH
-THE HIGHER THE VOLTAGE , THE HIGHER THE TEMP RISING
FOR ASUS A43TK OR SIMILAR : 3.0GHz ARE NOT stable on ASUS A43TK .It only gives you a bluescreen because of voltage limitation.... 2.9GHz are more stable but need a good cooler .( DON'T USE CHEAP COOLER as it not good as branded ones :shakehead: ...laptop cooler with adjustable fan like Cooler Master Notepal U3 for example is good to be used in overclocking things :clap: )
To have a better temperature on cooling , make a homemade laptop cooler by using some high airflow of 120mm case fans ( mine using cooler master and xigmatek ) plus a computer powersupply .. by using the homemade laptop cooler , i got a dramatically low temperature from 51'c is the minimum lowered to below 45'c ~ The temp wont go above 85'c
NOTES :
Some of you guys might have problem with application profiles or switchable graphic settings which is giving you an ati crash ..... to fix it u gotta do this :
1 - Go to C: drive (or whatever drive you use in tht matter) inside C : drive there is hidden folder called ProgramData go inside this folder and you will see ATI folder delete ATI folder. (programdata folder is hidden so you have to change your folder view options to show hidden folders)
2 - Go to C:\Users\yourwindowsuser\AppData\Local (change yourwindowsuser with your admin account name that you use when you login windows) there you will see another ATI folder just delete it.
3- Try to reopen the CCC . Everything will start fine. CCC will work fine but all your previous profiles gone
Hope ATI will fix this issue ....
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Upgrade or install windows 8 for better gaming performance :) the fps of myself playing mw2 stable at 50-60fps :) most games like cod bops also gained a huge amount of fps :)
[b]TWEAKS:[/b]
Make BF3 running smoother ~ :
First , you need to set ur settings that make the game ran playable . then , download the .cfg file and put in in ur battlefield 3 folder .
http://www.mediafire.com/?l8uyt1qxcns1w3u
For smooth or increase performance on Battlefield 3 , patch ur game until latest ~ since i test the game using the pirate one , use update 5 of battlefield 3 .search through google or can ask me to upload the file of the patch ( but tht would be illegal :P )
This is wht i got through fps benchmark :
Operation Swordbreaker ( in the humvee scene ~ till end of mission )
B4 Patch : 35~39 fps
After patch : 39~60 fps minimum is around 28 or 29 but happen on certain , not all the time ~ still playable
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
[b]FOR USING THE HD7670M INSTEAD OF HD6520G[/b]
This is a detail explaination on getting a performance on 7670m card without using 6520g ...
-Right click , go to AMD Radeon Dual Graphic tab and disable it .
-Then , go to Switchable Graphics and select ur desired application that you wanna run with 7670m .select high performance ~ done .
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
You guys are feel free to ask the game settings or overclock settings at me if you guys wanna know my clock setup ^w^
Stay tune for more stable benchmark and oc . It would be a great if you guyz post ur oc result at here so we can exchange some infos ^w^
If you guys have any suggestion , please let me know .And also ,please leave a good comment ... Don't be harsh ....
Stay update to latest ATI graphic driver on AMD websites . watch out for game latest patch for performance and other improvement and fixes .
For Benchmarking software or games can be requested at this post for further benchmarking n testing
Sharing is Caring
Official Post by Ahmad Nasri ( Frostbiteengine/ Frosty / Frost ) Malaysia Boleh !
Thank You for Viewing my post !
